Keep your line running 24/7
SMERT cobots bring 24/7 precision to assembly lines, welding stations, and quality control. Β±0.02mm repeatability, 10 safety functions, IP66 rated.
- Assembly, welding & quality checks
- Β±0.02 mm repeatability
- See it working in our Hong Kong lab
Repeatability
Operation
ROI Payback
MTBF
Manufacturing Applications
From assembly to inspection, one versatile robot platform for all your needs
Assembly Automation
Precision component assembly for electronics, automotive, and consumer products
Sub-millimeter accuracy for circuit boards, mechanical assemblies, and delicate components.
Welding & Joining
Consistent, high-quality welds with perfect repeatability
Spot welding, arc welding, and adhesive application with zero defects.
Painting & Coating
Uniform coating application with minimal waste
Powder coating, spray painting, and protective finishes with perfect coverage.
Quality Inspection
AI-powered visual inspection for defect detection
Real-time quality control with computer vision identifying defects humans miss.
Material Handling
Loading, unloading, and machine tending automation
Seamless integration with CNC machines, injection molding, and press operations.
Find Your Perfect Cobot
Answer a few questions and let our AI analyze our complete robot and gripper catalog to find the ideal solution for your specific needs.
Industrial Safety Standards
SMERT cobots meet the highest safety standards for manufacturing environments, enabling fence-free operation alongside human workers.
Certifications & Compliance
ISO 10218-1/2
Robot Safety
Industrial robot safety requirements
ISO 13849-1 PLd
Safety Control
Performance Level d safety systems
ISO/TS 15066
Cobot Safety
Collaborative robot force limiting
IEC 62443
Cybersecurity
Industrial automation security
CE-EMC, CE-MD
EU Conformity
EMC & Machinery Directive
FCC, NRTL, UL
US Compliance
Federal & UL certifications
ISO 3834
Welding Quality
Fusion welding quality requirements
AWS D1.1
Structural Welding
Structural welding code
10 Built-in Safety Functions
Joint Position Monitoring
Real-time tracking of all 6 axes
TCP Speed Limiting
Maximum 3m/s with configurable limits
TCP Force Limiting
Per ISO/TS 15066 body region limits
Elbow Force Limiting
Prevents pinch-point injuries
Momentum Limiting
Dynamic energy control
Power Limiting
Maximum 80W collaborative mode
Collision Detection
Immediate stop on contact
Safe Stop (SS1/SS2)
Category 1 & 2 stop functions
Safety-Rated Monitored Stop
For human interaction zones
E-Stop Integration
Hardwired emergency circuits
ISO/TS 15066 Compliant Force Limits
Our cobots automatically limit forces based on body region contact thresholds: 140N (hand/finger), 210N (arm), 250N (torso) β enabling true fence-free collaboration with zero serious injury risk.
Manufacturing Robot Family
Heavy payload models optimized for assembly, welding, and material handling with extended reach
Recommended: S15 for assembly, S20/S30 for welding, S40/S50 for heavy part handling
Model Comparison
| Model | Payload | Reach | Weight | Power | Speed | Repeatability | IP Rating |
|---|---|---|---|---|---|---|---|
| SMERT S10 | 10kg | 1000mm | 43kg | 350W | 3.0m/s | Β±0.03mm | IP54 (IP66 opt) |
| SMERT S15 | 15kg | 1300mm | 60kg | 600W | 2.5m/s | Β±0.05mm | IP54 |
| SMERT S20 | 20kg | 1700mm | 64kg | 800W | 2.2m/s | Β±0.05mm | IP54 |
| SMERT S30 | 30kg | 1800mm | 93kg | 1000W | 2.0m/s | Β±0.05mm | IP54 |
| SMERT S35 | 35kg | 1800mm | 89kg | 1000W | 2.0m/s | Β±0.05mm | IP54 |
| SMERT S40 | 40kg | 1800mm | 95kg | 1200W | 1.8m/s | Β±0.05mm | IP54 |
| SMERT S50 | 50kg | 2000mm | 110kg | 1500W | 1.5m/s | Β±0.05mm | IP54 |
6 DOF
Degrees of Freedom
225Β°/s
Max Joint Speed
3m/s
Max TCP Speed
10
Safety Functions
Joint Specifications
| Joint | Range | Max Speed |
|---|---|---|
| J1 (Base) | Β±360Β° | 180Β°/s |
| J2 (Shoulder) | Β±135Β° | 180Β°/s |
| J3 (Elbow) | Β±155Β° | 180Β°/s |
| J4 (Wrist 1) | Β±360Β° | 225Β°/s |
| J5 (Wrist 2) | Β±180Β° | 225Β°/s |
| J6 (Wrist 3) | Β±360Β° | 225Β°/s |
I/O Specifications
Control Box Options
Standard Control Box
445Γ237Γ420mm, 18.3kg
Mini Control Box
323Γ221Γ80mm, 2.5kg
Teach Pendant
11" 1920Γ1200 touchscreen
Communication
- TCP/IP
- ModbusTCP
- Profinet (opt)
- EtherNet/IP (opt)
- OPC-UA
- ROS/ROS2
Certifications
- CE-EMC, CE-MD
- ISO 13849-1 PLd
- ISO/TS 15066
- FCC, NRTL, UL
- MTBF: 50,000 hrs
AI Vision System
Advanced computer vision for quality inspection and defect detection
Industrial-Grade Computer Vision
Integrated AI vision solution powering precision automation with Β±0.1mm accuracy
24 Vision Features
AI-Powered Capabilities
Electric Gripper System
Precise force control for delicate assembly and robust material handling
Dexterous Hands & Electric Grippers
Complete SMERT end-effector ecosystem β LinkerBot L30, L20 and O6 dexterous hands for care and service work, plus servo-electric parallel grippers (Β±0.03mm) for industrial pick-and-place
Complete Gripper Lineup
| Model | Type | Force | Payload | Stroke | IP | Application |
|---|---|---|---|---|---|---|
| SMERT-PGE-8 | Parallel | 2-8N | 0.1kg | 14mm | IP54 | Micro assembly, electronics |
| SMERT-PGC-50 | Parallel | 15-50N | 1kg | 37mm | IP54 | Electronics, small parts |
| SMERT-PGC-140 | Parallel | 40-140N | 3kg | 50mm | IP67 | General purpose (PRIMARY) |
| SMERT-PGC-300 | Parallel | 80-300N | 6kg | 60mm | IP67 | Heavy duty handling |
| SMERT-PGH-400 | Parallel | 140-400N | 8kg | 80mm | IP67 | Palletizing, heavy parts |
| SMERT-RGI-100 | Rotary | 30-100N | 2kg | Infinite rotation | IP54 | Pick & rotate operations |
| SMERT-RGD-35 | Rotary | 10-35N | 1kg | 1500Β°/s | IP54 | High-speed orientation |
| SMERT-CGC-80 | 3-Finger | 20-80N | 1.5kg | Ξ¦10-Ξ¦130mm | IP67 | Cylindrical objects |
| FlagshipLinkerHand L30 | Bionic Hand | tendon drive, 0.2s open/close | 30kg | 22 DoF (18 active + 4 passive), 5-finger anthropomorphic | β | FLAGSHIP β heaviest payload, two-handed transfer and lifting |
| FlagshipLinkerHand L20 | Bionic Hand | 15N per fingertip, piezoresistive tactile | 20kg | 21 DoF (16 active + 5 passive), 5-finger anthropomorphic | β | Hygiene, delicate handling, eldercare and disability care |
| FlagshipLinkerHand O6 | Bionic Hand | 70N grip | 50kg | 11 DoF (6 active + 5 passive), 360g | β | Lightweight service and retail tasks |
| SMERT-AG-160 | Adaptive | 45-160N | 3kg | 95mm | IP54 | Irregular shapes, variable items |
Key Features
Precise Force Control
0.1N precision adjustment for delicate to heavy-duty gripping tasks
Lower Energy & Cleaner
No air lines, no compressor noise β cleaner and more efficient than pneumatic
Intelligent Sensing
Real-time drop detection, grip confirmation, and position feedback
Complete Range Available
Micro precision (2-8N) β’ Light duty (15-50N) β’ General purpose (40-140N) β’ Heavy duty (300-400N) β’ Rotary β’ 3-Finger centric β’ Adaptive
Why Automate with SMERT
24/7 Production
Continuous operation without breaks or shifts
99.9% Quality
Consistent precision eliminates human error
Faster Cycles
Reduced cycle times and increased throughput
ROI in 12 Months
Rapid payback with measurable savings
Industries We Serve
Automotive
- Body welding and assembly
- Parts inspection
- Material handling
- Paint application
Electronics
- PCB assembly
- Component placement
- Soldering automation
- Testing & QC
Aerospace
- Precision drilling
- Composite layup
- Surface finishing
- Assembly verification
Ready to Automate Your Production?
Our engineering team will assess your requirements and design a custom automation solution.
Proven in the industry
Published results from real deployments around the world β the same tasks we scope, program and support for you.
Cobot feeding a CNC lathe 10β12 hours a day in a five-person machine shop.
- βPayback in three months
- βProduction cost-competitive with Asian outsourcing; first program written in 90 minutes
UR5 cobot (Universal Robots)
Source: Universal RobotsModular cobot cells tending CNC milling, mill-turn, CMM and laser-marking machines for high-precision parts.
- βOverall equipment effectiveness up from ~70% to ~95%
- βHundreds of production hours added annually; payback in 12β18 months
UR5/UR10 cobots with acubez automation (Universal Robots)
Source: Universal RobotsSix cobots handling balloon inflation, sewing and product assembly for a bespoke promotional-products maker.
- βFood-flag output up from 250,000 to 15 million per year
- βROI in nine months; production kept in the UK
UR3 cobots (Universal Robots)
Source: Universal RobotsThese are published third-party deployments, not smert.ai projects. smert.ai is not affiliated with, endorsed by, or sponsored by the companies or robot manufacturers named. Brand names appear in plain text for factual reference only.
